WF28 10pin Waterproof Connector Aviation Bulkhead Power Plug Socket 25A
Product details
| Management number | 247733272 | Release Date | 2026/08/16 | List Price | US$7.20 | Model Number | 247733272 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- WS28 5pin 7pin 10pin 12pin 16pin 17pin 20pin 24pin 26pin IP67 Waterproof Bulkhead Connector Set Plug Socket
- 5pin, 7pin, 10pin: Rated Current (A): 25A Contact diameter × number: Φ2.5x5 / Φ2.5x 7 / Φ2.5x 10 Rated voltage (AC.V.): 500V Withstanding Voltage (AC.V) 1 minute: 1500V Contact resistance: 1mΩ Cable specification: <2.5m㎡/12AWG
- 12pin, 16pin, 17pin: Rated Current (A): 10A Contact diameter × number: Φ1.5x12 / Φ1.5x16 / Φ1.5x17 Rated voltage (AC.V.): 500V Withstanding Voltage (AC.V) 1 minute: 1500V Contact resistance: 2.5mΩ Cable specification: <1m㎡/16AWG
- 20pin, 24pin, 26pin: Rated Current (A): 5A Contact diameter × number: Φ1.0x20 / Φ1.0 x24 / Φ1.0 x26 Rated voltage (AC.V.): 400V Withstanding Voltage (AC.V) 1 minute: 1200V Contact resistance: 5mΩ Cable specification: <0.785m㎡/18AWG
- Coupling: Threaded Coupling Shell Material: Zinc alloy Insert Material: PPS man temperature 260° Contact material: Brass (gold-plated) Termination: solder Cable outer diameter range：10-15.5mm(PG16) Protection level: IP65 Durability: ≥500 times Working temperature: -25℃～60℃ What's in the package: 1 plug +1 socket with cap + 4 set screw
| ASIN | B0DB259GYN |
|---|---|
| Item Weight | 6.4 ounces |
| Manufacturer | MCcamstore |
| Package Dimensions | 4.9 x 3.7 x 1.2 inches |
